ATS Series Installation Manual10
11. Specifications
Technical Specifications SYNCRO
ATS-3V3
TEMPO
ATS-2V3
Rated voltage range: 230V - 240V 230V - 240V
Rated frequency: 50Hz 50Hz
Rated power input: 225W 225W
Door opening:
Maximum Door Area:
Maximum Door Weight:
18m
2
235kg*
18m
2
200kg*
Door must be well balanced and able to be operated by hand, as per warranty conditions and AS/NZS 4505:2012
Minimum headroom 57mm 57mm
Rated Operating Time 4 mins 4 mins
Rated Temp +5
o
C to +40
o
C +5
o
C to +40
o
C
Short Term Peak force: 1100N 1100N
Door travel speed (mm/sec) 180mm 180mm
Rated load 400N 400N
Maximum lifting under spring tension 200N (20kg) 200N (20kg)
Receiver type Multi-frequency UHF Multi-frequency UHF
Receiver code storage capacity 64 X 4-button Transmitters 64 X 4-button Transmitters
Transmitter battery CR2032 (3 Volts) CR2032 (3 Volts)
Main light 1 x LED (module) 1 x LED (module)
Network connectivity Network ready,
Smart hub already installed
Requires optional
(Smart Phone Control Kit)
* Gross door weight, including all fittings
Note: During the open and close cycles, intermittent operations may occur in areas which experience very strong winds. The
strong wind puts extra pressure on the door and tracks which may in turn intermittently trigger the safety obstruction detection
system.
