The Data Output Format
The image and 3D data output is performed by selecting the data channel DC0-DC2 (node Camera Controls→DataOutput). Depending on the
algorithm the data can be acquired by enabling the corresponding output Data Channel (DC). Every DC is saved in a new image row. The bit depth
of output data depends on the selected algorithm. In 3D mode the camera outputs data with 16 bit. In Image mode the camera can output 8 or 16
bit data. When in 8 bit Image mode, the DC0 delivers the 8 most significant bits of the 10 bit intensity data.
The Data Channel Assignment DC0, DC1 and DC2
Camera Mode
FIR
FIRMode
DC0
DC1
DC2
False
-
Sensor intensity
Not used
Not used
True
Derivative
First derivative of sensor
intensity
Not used
Not used
True
Smoothing
Smoothed sensor intensity
Not used
Not used
MaximumIntensity
False
-
Maximum intensity of Gauss
Position of rising edge of Gauss
(PosL)
Position of maximum intensity of
Gauss (PosM)
True
Smoothing
Maximum intensity of Gauss
detected in smoothed sensor
Position of rising edge of Gauss
(PosL) detected in smoothed sensor
Position of maximum intensity of
Gauss (PosM) detected in smoothed
sensor image
Threshold
False
-
Maximum intensity of Gauss
- Position of rising edge of Gauss
(PosL)
or
- Gauss width (PosR-PosL)
- Position of falling edge of Gauss
(PosR)
or
- Position of Gauss with 1/2 pixel
resolution (PosL+PosR)
True
Smoothing
Maximum intensity of Gauss
detected in smoothed sensor
- Position of rising edge of Gauss
(PosL)
or
- Position of falling edge of Gauss
(PosR)
or
