Automation Technology C2-2040-GigE User Manual

C2 Series User Manual Rev. 1.9

35
The C2 Series Triggering Mode
Description of Profile Trigger Modes
No.
Profile Trigger Mode (PTM)
0
Free-run (PTM0)
1
Camera input 1 (PTM1)
2
Camera input 2 (PTM2)
3
Encoder/Resolver Interface (PTM3)
t
Profile
Acquisition 1
Profile
Acquisition 2
Profile
Acquisition 3
IN1
Profile
Acquisition 4
t
Profile
Acquisition 1
Profile
Acquisition 2
Profile
Acquisition 3
IN2
Profile
Acquisition 4
Profile
Acquisition 1
A
B
RS422
Example: Trigger after number of steps = 4
Counter
Internal
Trigger
Profile
Acquisition 2
Profile
Acquisition 3
t
ENC_A
ENC_B
