Automation Technology C2-2040-GigE - Page 51

C2 Series User Manual Rev. 1.9

49
Clamp No.
Signal Name
Description
J300/8
SHIELD
Camera shield
J301/1
GND
Encoder ground
J301/2
Z-
RS422 encoder index track Z-
J301/3
Z+
RS422 encoder index track Z+ / single-ended index track Z
J301/4
B-
RS422 encoder track B-
J301/5
B+
RS422 encoder track B+ / single-ended track B
J301/6
A-
RS422 encoder track A-
J301/7
A+
RS422 encoder track A+ / single-ended track A
J301/8
SHIELD
Camera shield
J400/1
GND_IO
I/O ground
J400/2
PWR_IO
Power supply voltage of camera isolated outputs (9V-24V DC)
J400/3
HV-OUT1
Isolated output #1 (9V-24V)
J400/4
HV-OUT2
Isolated output #2 (9V-24V)
J400/5
OUT1
Isolated output #1 (5V)
J400/6
OUT2
Isolated output #2 (5V)
J400/7
IN1
Isolated input #1 (5V/24V)
J400/8
IN2
Isolated input #2 (5V/24V)
J500/1
VCC_L
Input power supply voltage for laser control
J500/2
VCC_L
Input power supply voltage for laser control
J500/3
GND_L
Input ground for laser control
J500/4
GND_L
Input ground for laser control
J500/5
DO
Output for digital modulation of laser (TTL signal)
J500/6
AO
Output for analog modulation of laser (0-5V DC)
J500/7
AI
Analog Input for monitoring specific functions of laser (0-5V DC)
J500/8
SDA
Data line of I²C bus interface
J500/9
SCL
Clock line of I²C bus interface
J500/10
SHIELD
Camera shield
