GS1 AC Drive Specifications
Chapter 1: Getting Started
100V Class
Model Name GS1-10P2 GS1-10P5
Motor Rating
HP
1/4HP 1/2HP
kW
0.2kW 0.4kW
Rated Input Voltage
Single-phase 100-120VAC ±10%, 50/60Hz, ±5%
Maximum Output Voltage
Three-phase: 200-240VAC ( x2 of input voltage)
Rated Input Current (A)
6 9
Rated Output Current (A)
1.6 2.5
Watt Loss 100% (I)
19.2 19.2
Dimensions (HxWxD)
132.0mm (5.20”) x 68.0mm (2.68”) x 128.1mm (5.04”)
200V Class
Model Name GS1-20P2 GS1-20P5 GS1-21P0 GS1-22P0
Motor Rating
HP
1/4HP 1/2HP 1HP 2HP
kW
0.2kW 0.4kW 0.7kW 1.5kW
Rated Input Voltage
Single/three-phase: 200-240VAC ± 10%,
50/60Hz ±5%
Three-phase: 200-240VAC ± 10%,
50/60Hz ±5%
Maximum Output Voltage
Three-phase: 200-240VAC (proportional to input voltage)
Rated Input Current (A)
4.9/1.9 6.5/2.7 9.7/5.1 9
Rated Output Current (A)
1.6 2.5 4.2 7.0
Watt Loss 100% (I)
18.4 26.8 44.6 73
Dimensions (HxWxD)
132.0mm (5.20”) x 68.0mm (2.68”) x 128.1mm (5.04”)
