Compatible Dir ectLOGIC PLCs and Modules
The following tables show which DirectLOGIC PLCs and modules can be used
with the GS1 Series AC Drive.
Appendix B: Using GS1 AC Drives with DirectLOGIC PLCs
GS1 Series AC Drive User Manual
B–2
DirectLOGIC PLC Modules for Use with GS1 AC Drives
DL05 PLCs
D0-05AR
DL05 CPU, 8 AC in / 6 Relay out, 110/220VAC Power Supply. Inputs: 8 AC inputs,
90-120 VAC, 2 isolated commons. Outputs: 6 Relay outputs, 6-27 VDC, 6-240 VAC, 2A/pt.
max., 2 isolated commons
D0-05DR
DL05 CPU, 8 DC in / 6 Relay out, 110/220VAC Power Supply. Inputs: 8 DC inputs,
12-24 VDC current sinking/sourcing, 2 isolated commons. Outputs: 6 Relay outputs,
6-27 VDC, 6-240 VAC, 2A/pt. max., 2 isolated commons
D0-05DD
DL05 CPU, 8 DC in / 6 DC out, 110/220VAC Power Supply. Inputs: 8 DC inputs, 12-24 VDC
current sinking/sourcing, 2 isolated commons. Outputs: 6 DC outputs, 6-27 VDC current
sinking, 1.0A/pt. max.
D0-05DD-D
DL05 CPU, 8 DC in / 6 DC out, 12/24VDC Power Supply. Inputs: 8 DC inputs, 12-24 VDC
current sinking/sourcing, 2 isolated commons. Outputs: 6 DC outputs, 6-27 VDC current
sinking, 1.0A/pt. max.
D0-05DR-D
DL05 CPU, 8 DC in / 6 Relay out, 12/24VDC Power Supply. Inputs: 8 DC inputs, 12-24 VDC
current sinking/sourcing, 2 isolated commons. Outputs: 6 Relay outputs, 6-27 VDC,
6-240 VAC, 2A/pt. max., 2 isolated commons
DL06 PLCs
D0-06DD1
DL06 CPU, 20 DC in / 16 DC out, 110/220VAC Power Supply, with 0.3A 24VDC Auxiliary
Device Power Supply. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated
commons (4 inputs per common). Outputs: 16 DC outputs, 12-24 VDC current sinking,
1.0A/pt. max., 4 commons non-isolated (4 points per common).
D0-06DR
DL06 CPU, 20 DC in / 16 Relay out, 110/220VAC Power Supply, with 0.3A 24VDC Auxiliary
Device Power Supply. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated
commons (4 inputs per common). Outputs: 16 Relay outputs, 6-27 VDC, 6-240 VAC, 2A/pt.
max., 4 isolated commons (4 points per common).
D0-06AR
DL06 CPU, 16 AC in / 20 Relay out, 110/220VAC power supply, with 0.3A 24VDC auxiliary device
power supply. Inputs: 20 AC inputs, 90-120 VAC, 5 isolated commons (4 inputs per common). Outputs:
16 Relay outputs, 6-27 VDC, 6-240 VAC, 2A/pt. max., 4 isolated commons (4 points per common).
D0-06DD1-D
DL06 CPU, 20 DC in / 16 DC out, 12/24VDC Power Supply. Inputs: 20 DC inputs, 12-24 VDC
current sinking/sourcing, 5 isolated commons (4 inputs per common). Outputs: 16 DC outputs,
12-24 VDC current sinking, 1.0A/pt. max., 4 commons non-isolated (4 points per common).
D0-06DR-D
DL06 CPU, 20 DC in / 16 Relay out, 110/220VAC Power Supply. Inputs: 20 DC inputs,
12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). Outputs: 16
Relay outputs, 6-27 VDC, 6-240 VAC, 2A/pt. max., 4 isolated commons (4 points per common).
DL05/DL06 DC Input/Output Module
D0-08CDD1
4 pt. 12-24VDC current sinking/sourcing input, 1 common, 4 pt. 12-24VDC sinking output,
0.3A/point, 1.2A/module, removable terminal, no fuse
DL05/DL06 DC Output Modules
D0-10TD1
10 pt. 12-24 VDC current sinking output module, 2 commons non-isolated (5 pts. per
common), 0.3A/point, 1.5A/common, removable terminal, no fuse
D0-16TD1
16 pt. 12-24 VDC current sinking output module, 2 commons non-isolated (5 pts. per
common), 0.3A/point, 1.5A/common, removable terminal, no fuse.
