GS1 Series AC Drive User Manual
B–3
Appendix B: Using GS1 AC Drives with DirectLOGIC PLCs
DirectLOGIC PLC Modules for Use with GS1 AC Drives (cont.)
DL05/DL06 Analog Module
F0-2AD2DA-2
2 channel in, 2 channel out voltage analog option card; 0-5V, 0-10V
F0-4AD2DA-2
4 channel in, 2 channel out voltage analog option card; 0-5V, 0-10V
F0-4AD2DA-1
4 channel in, 2 channel sourcing out current analog option card; 4-20mA
DL105 PLCs
F1-130DR
DL06 CPU, 20 DC in / 16 DC out, 110/220VAC Power Supply, with 0.3A 24VDC Auxiliary
Device Power Supply. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated
commons (4 inputs per common). Outputs: 16 DC outputs, 12-24 VDC current sinking,
1.0A/pt. max., 4 commons non-isolated (4 points per common).
F1-130DD-D
DL130 CPU, 10 DC in / 8 DC out, 12/24VDC Power Supply. Inputs: 10 DC inputs, 12-24
VDC current sinking/sourcing, 3 isolated commons. Outputs: 8 DC outputs, 5-30VDC
current sinking, 0.5A/pt. max, 3 internally connected commons.
F1-130DR-D
DL130 CPU, 10 DC in / 8 Relay out, 12/24VDC Power Supply. Inputs: 10 DC inputs, 12-24
VDC current sinking/sourcing, 3 isolated commons. Outputs: 8 relay outputs, 12-30 VDC,
12-250VAC, 7A/pt. max., 4 isolated commons
F1-130DD-D
DL130 CPU, 10 DC in / 8 DC out, 12/24VDC Power Supply. Inputs: 10 DC inputs, 12-24
VDC current sinking/sourcing, 3 isolated commons. Outputs: 8 DC outputs, 5-30VDC
current sinking, 0.5A/pt. max, 3 internally connected commons.
DL205 DC Output Module
D2-16TD1-2
16 pt. 12-24 VDC current sinking output module, 1 common (2 common terminals),
0.1A/point, 1.6A/module, no fuse, European type removable terminal
D2-32TD1
32 pt. 12-24 VDC current sinking output module. 1 common (4 common terminals),
0.1A/point, 3.2A/module, no fuse.
DL205 Relay Output Modules
D2-04TRS
4-pt. 5-30 VDC or 5-240 VAC isolated relay output module, 4 Form A (SPST) relays, 4
commons, 4A/point, 8.0A/module, replaceable fuse, removable terminal
D2-08TR
8-pt. 5-30 VDC or 5-240 VAC output module, 8 Form A (SPST) relays, 1 common (2
common terminals), 1A/point, 4.0A/module, replaceable fuse, removable terminal
F2-08TR
8-pt relay output, 10A/common, 5-30VDC or 5-240VAC
F2-08TRS
8-pt. 12-28 VDC or 12-240 VAC output module, 5 Form A (SPST) relays, 3 Form C (SPDT)
relays, 8 isolated commons, 7A/point max., no fuses, removable terminal
D2-12TR
12 pt. 5-30 VDC or 5-240 VAC relay output module, 12 Form A (SPST) relays, 2 commons,
1.5A/point max., 3.0A/common, 2 replaceable fuses, removable terminal
DL205 DC Input/Output Modules
D2-08CDR
4 pt. 24VDC sinking/sourcing input, 1 common, 4 pt. relay output, 1A/pt., 4A/module, 1
common, replaceable fuse
DL205 Analog Output Module
F2-02DAS-1
2 channel, 16-bit resolution, Isolated 4-20mA sourcing (2 isolated commons). Designed to
operate with 24 VDC user-supplied power supply.
F2-02DAS-2
2 channel analog output, 16 bit resolution, isolated, range: 0-5V, 0-10V (2 isolated
commons). Designed to operate with 24 VDC user-supplied power supply.
F2-08DA-1
8 channel analog output module, 12 bit resolution, range: 4-20mA, sink or source output
configurable. Designed to operate with 24 VDC user-supplied power supply.
F2-02DA-2
2 channel analog output module, 12 bit resolution, ranges: 0-5V, 0-10V, -5 to +5V, -10 to
+10V. Designed to operate with 24 VDC user-supplied power supply.
F2-08DA-2
8 channel analog output module, 12 bit resolution, ranges: 0-5V, 0-10V. " Designed to
operate with 24 VDC user-supplied power supply.
