Appendix B: Using GS1 AC Drives with DirectLOGIC PLCs
GS1 Series AC Drive User Manual
B–4
DirectLOGIC PLC Modules for Use with GS1 AC Drives (cont.)
DL305 AC/DC Output Modules
D3-08TR
8 pt. 5-30 VDC or 5-220 VAC output module, 5A/point DC or 4A/point AC, 8 Form A relays
(SPST), 2 commons (isolated), non-removable terminal, 2 user replaceable fuses
D3-16TR
16 pt. 5-30 VDC or 5-220 VAC output module, 2A/point,16 Form A relays (SPST), 2
commons (isolated), removable terminal, no internal fuses
DL305 Analog Output Modules
F3-04DAS
4 channel isolated analog output module, 12 bit resolution, ranges: 0 to 5V, 0 to 10V, -5 to
+5V, -10 to +10V, 4 to 20mA, 0 to 20mA. -750 to +750 VDC channel to channel isolation
DL405 DC Output Modules
D4-08TD1
8 pt. 12-24 VDC current sinking output module, 2 commons (internally connected),
2A/point, 5A/common, removable terminal
D4-16TD1
16 pt. 5-24 VDC current sinking output module, 2 commons (internally connected),
0.5A/point, 3A/common, removable terminal
D4-32TD1
32 pt. 5-24 VDC current sinking output module, 4 commons (isolated), 0.2A/point,
1.6A/common. Requires one connector, sold separately.
DL405 AC/DC Output Modules
D4-08TR
8 pt. 5-30 VDC or 5-250 VAC output module, 8 Form A (SPST) relays, 2 commons (isolated),
2A/point, 5A/common, removable terminal
F4-08TRS-1
8 pt. 12-30 VDC or 12-250 VAC isolated output module, 4 Form A (SPST) and 4 Form C
(SPDT) relays, 8 commons (isolated), 10A/point, 40A/module, removable terminal.
F4-08TRS-2
8 pt. 12-30 VDC or 12-250 VAC isolated output module, 4 Form A (SPST) relays and 4 Form C
(SPDT) relays, 8 commons (isolated), 5A/point, 40A/module, replaceable fuses, removable terminals.
D4-16TR
16 pt. 5-30 VDC or 5-250 VAC output module, 8 Form A (SPST) relays, 2 commons
(isolated), 1A/point, 5A/common, removable terminals.
DL405 Analog Output Modules
F4-04DAS-1
4 channel analog output module, 16 bit resolution, isolated, range: 4 to 20mA current sourcing.
F4-04DAS-2
4 channel analog output module, 16 bit resolution, isolated, range: 0-5V, 0-10V.
F4-08DA-2
8 channel analog output module, 12 bit resolution, range: 0-5V or 0-10V
F4-16DA-2
16 channel analog output module, 12 bit resolution, range: 0-5V or 0-10V.
