GS1 Series AC Drive User Manual
B–5
Appendix B: Using GS1 AC Drives with DirectLOGIC PLCs
DirectLOGIC PLC Modules for Use with GS1 AC Drives (cont.)
Terminator I/O DC Output Modules
T1K-08TD1
8 pt. 12-24 VDC current sinking output module, 4 points per common, 1.0A/point, 2
replaceable fuses (T1K-FUSE-1). (use with T1K-08B or T1K-08B-1 terminal base)
T1K-16TD1
16 pt. 12-24 VDC current sinking output module, 4 points per common, 1.0A/point, 4
replaceable fuses (T1K-FUSE-1). (use with T1K-16B or T1K-16B-1 terminal base)
Terminator I/O AC/DC Output Modules
T1K-08TR
8 pt. 5-30 VDC or 5-240 VAC output module, 8 Form A (SPST) relays, 4 points per common,
2.0A/point max., 2 replaceable fuses (T1K-FUSE-2). (use with T1K-08B or T1K-08B-1
terminal base)
T1K-16TR
16 pt. 5-30 VDC or 5-240 VAC output module, 16 Form A (SPST) relays, 4 points per
common, 2.0A/point max., 4 replaceable fuses (T1K-FUSE-2). (use with T1K-16B or T1K-
16B-1 terminal base)
T1K-08TRS
8 pt. 5-30 VDC or 5-240 VAC isolated relay output module, 8 Form A (SPST) relays, 1 point
per common, 7.0A/point max., 8 replaceable fuses (T1K-FUSE-3). (isolation requires use of
T1K-16B or T1K-16B-1 terminal base)
Terminator I/O Analog Output Modules
T1F-08DA-2
8 channel analog output, 12 bit resolution, range: 0-5VDC, 0-10VDC, +/-5VDC,
+/-10VDC. (use with T1K-08B or T1K-08B-1 terminal base)
T1F-16DA-2
16 channel analog output, 12 bit resolution, range: 1-5VDC, 1-10VDC, +/-5VDC, +/-
10VDC. (use with T1K-16B or T1K-16B-1 terminal base)
