Analog Input Examples
Use the equations below when calculating the values for the Maximum Output
Frequency, Analog Input Offset, Analog Input Gain, and the Mid-point Frequency.
A)
Note: The Maximum Output Frequency is not a parameter setting but is needed in order
to calculate the Analog Gain. The default Maximum Output Frequency for the GS1 drive
is 60Hz. If parameters 0-02, 0-03, or 0-04 are changed, then the Maximum Output
Frequency will change.
B)
C)
D)
Note: The Mid-point Frequency calculation shows the frequency reference of the drive
when the potentiometer or other analog device is at its mid-point.
+ Min. Freq. Reference
Mid-point Freq. =
2
Max. Freq. Reference – Min. Freq. Reference
()
Analog Gain % =
Maximum Output Frequency
Max. Frequency Reference – Min. Frequency Reference
()
x 100
x 100
Analog Offset % =
Min. Frequency Reference
Max. Frequency Reference
()
x Base Frequency (0-02)
Max. Output Frequency =
Motor Max. RPM (0-04)
Motor Base RPM (0-03)
()
GS1 Series AC Drive User Manual
4–31
Chapter 4: AC Drive Parameters
