Non-Isolated Voltage or Sourcing Current Analog Output Modules
Appendix B: Using GS1 AC Drives with DirectLOGIC PLCs
GS1 Series AC Drive User Manual
B–8
Non-Isolated Voltage
or Sourcing Current
Analog Output Modules
OV
+I/+V
0 –
+
10V
or
4 – 20m
A
Control circuit terminal Shielded leadsMain circuit (power) terminals
GS1-xxxx
T3
T1
T2
+10V 10mA
(max)
AI
CM
L1
L3
L2
R1O
R1
16
DI1
DI2
DI3
DI4
CM
• F0-02AD2DA-2
• F0-04AD2DA-1
• F0-04AD2DA-2
• F2-02DAS-1
• F2-02DAS-2
• F2-08DA-1
• F2-02DA-2
• F2-08DA-2
• F4-08DA-2
• F4-16DA-2
• T1F-08DA-2
• T1F-16DA-2
• T1F-8AD4DA-1
• T1F-8AD4DA-2
