Motor Base Frequency Mem Addr: 0002H(40003)
Range: 50/60/400 Default Setting 60
•This value should be set according to rated frequency of the motor as indicated on
the motor nameplate. Maximum Voltage Frequency determines the volts per hertz
ratio.
Motor Base RPM Mem Addr: 0003H(40004)
Range: 375 to 9999 RPM Default Setting: 1750
• This value should be set according to rated Base RPM of the motor as indicated on
the motor nameplate.
Motor Maximum RPM Mem Addr: 0004H(40005)
Range: 0-03 to 9999 RPM Default Setting: 0-03
• This value should be set according to the desired maximum speed of the motor.
This value should not exceed the motor’s maximum rated speed.
0-04
0-03
0-02
Chapter 4: AC Drive Parameters
GS1 Series AC Drive User Manual
4–10
