100mm Hybrid Recorder
A-13
A. Recorder
B.•Indicator
C.•Converter
D.•Controller
E.•Thyristor•
•••••unit
F.•Pressure•
••••transmitter
G.•Temp.•
•••••transmitter
H.•Accessories
KRN100
KRN50
KRN100•displays•measuring•value•as•trend•graph,•bar•graph,•and•digital•number•display(1•channel,•8-channel,•12-channel).•You•can•
select•one•by•the• ••key.•
Adjustment
Display changing
Digital number (12-channel)
Trend graph
Bar graph
Digital number (8-channel)
Digital number (1-channel)
RUN
mode
Parameter
setting
group
Screen display change
Special functions for record
3•sec.
3•sec.
3•sec.
3•sec.
Digital•memo
Manual•feed•(when•recording•stops)
Start/Stop•recording
Parameter•setting•information•print
Trend•graph
Bar•graph
Digital•number
Parameter
setting
Function•key
