100mm Hybrid Recorder
A-3
A. Recorder
B.•Indicator
C.•Converter
D.•Controller
E.•Thyristor•
•••••unit
F.•Pressure•
••••transmitter
G.•Temp.•
•••••transmitter
H.•Accessories
KRN100
KRN50
Type Model Function•and•number•of•channels Max.•mountable•cards Slot•number
Universal•input•card KRN-UI2 Universal•input•2-channel 6EA 1•to•6
Digital•input•card KRN-DI6 Digital•input•6-channel• 2EA
7•to•10
※
1
Alarm•output•card
KRN-AR4 Alarm•relay•output•4-channel• 3EA
KRN-AT6 Alarm•transistor•output•6-channel 2EA
Transmitter•power•output•card
KRN-24V3
Transmitter
24VDC•power•output•3-channel
4EA
Communication•output•card• KRN-COM
RS485•+•USB•+•Ethernet•communication•
output
1EA C
Item Description
①•Item
KRN100 New•100mm•Paper•Type•Recorder
②•Input•channel
02 2-channel(KRN-UI2×1EA)
04 4-channel(KRN-UI2×2EA)
06 6-channel(KRN-UI2×3EA)
08 8-channel(KRN-UI2×4EA)
10 10-channel(KRN-UI2×5EA)
12 12-channel(KRN-UI2×6EA)
③•Digital•input
0 None
1 6EA(KRN-DI6×1EA)
2 12EA(KRN-DI6×2EA)
④•Alarm•transistor•output
0 None
1 6EA(KRN-AT6×1EA)
2 12EA(KRN-AT6×2EA)
⑤•Alarm•relay•output
0 None
1 4EA(KRN-AR4×1EA)
2 8EA(KRN-AR4×2EA)
3 12EA(KRN-AR4×3EA)
⑥•Transmitter•power•output
0 None
1 3EA(KRN-24V3×1EA)
2 6EA(KRN-24V3×2EA)
3 9EA(KRN-24V3×3EA)
4 12EA(KRN-24V3×4EA)
⑦•Communication•output
0 None
1 RS485/Ethernet/USB(KRN-COM×1EA)
⑧•Power•voltage
0 100-240VAC,•50/60Hz
⑨•Case
S Standard•panel•mounting•type
Ordering information for recorder model
Ordering information for input/output card
Example of ordering
To•use•universal•input•10-channel,•digital•input•4-channel,•alarm•relay•output•5-channel,•and•RS485•communication•output,•it•is•
ordered•as•KRN100-10102-01-0S•and•the•connected•I/O•card•is•as•below.•
•
•
•KRN100(recorder):•1EA
•
•
•KRN-UI2(universal•input•card):•5EA•(universal•input•card•1EA•is•2-channel•and•5EA×2-channel•=•10-channel.)
•
•
•KRN-DI6(digital•input•card):•1EA
•
•
•KRN-AR4(alarm•relay•output•card):•2EA
•
•
•KRN-COM(Communication•output•card):•1EA
※
•1.•The•digital•input•card,•alarm•output•card,•transmitter•power•output•card•are•connectable•up•to•4EA•as•mixed.
KRN100 12 0 0 0 0 0 0 S
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨
Ordering information
