Autonics krn100 series Manual

100mm Hybrid Recorder
A-9
A. Recorder
B.•Indicator
C.•Converter
D.•Controller
E.•Thyristor•
•••••unit
F.•Pressure•
••••transmitter
G.•Temp.•
•••••transmitter
H.•Accessories
KRN100
KRN50
Special function [ Special Function ]
٧
Square
٧
Difference (deviation)
٧
Linear
٧
Root
It•displays•the•applied•measuring•value•of•the•set•special•
function.•Depending•on•Input•Type(Input•specication),•
applied•special•function•is•different.
•
•
•Set•range•:
• -•When•input•type(input•specication)•is•temperature•
sensor•(thermocouple,•RTD):•None•↔•Difference
• -When•input•type(input•specication)•is•analog•(voltage,•
current):•Linear•↔•Root•↔•Square•↔•Two•Unit
• (Two•Unit•is•displayed•when•Input•Type•(input•
specication)•is•set•as•0-20mA,•4-20mA.)
•
•
Factory•default:•None
In•case•of•voltage,•current•input•type,•this•mode•is•
used•when•input•value•is•calculated•by•square•for•the•
desired•display•value.•Reverse•of•Root,•ux•signal•is•
calculated•by•square•for•differential•pressure•signal.
Ex)•In•case•lower•limit•range:•-5V,•upper•limit•range:•
+5V•and•in•case•lower•limit•scale:•-1000,•upper•
limit•scale:•1000,•if•current•input•value•is•2V,•display•
value•is•-20.
It•is•available•to•set•when•Input•Type(input•
specication)•is•temperature•sensor•(thermocouple,•
RTD).•It•displays•the•deviation•of•Reference•Channel•
(Reference•channel)•measuring•value.•
(Display•value•=•standard•channel•measuring•value•-•
reference•channel•measuring•value)
•
•
The•set•channel•as•analog•(current,•voltage)•of•
Input•Type•(Input•specication)•is•not•able•to•set•as•
Reference•Channel•(reference•channel).
•
•
•If•there•is•no•set•reference•channel,•it•displays•
standard•channel•measuring•value.
•
•
If•any•one•of•reference•channel,•or•standard•channel•
is•break•(BURN),•upper•limit•value•(HHHH),•lower•
limit•value(LLLL)•status,•it•displays•as•correspond•
value.•If•you•select•the•channel•which•is•used•
Difference•function•as•reference•channel,•it•displays•
the•value•based•on•calculating•actual•measuring•
value,•not•display•value•of•reference•channel.
It•applies•lower•limit•scale•and•upper•limit•scale•to•lower•
limit•input•value•and•upper•limit•input•value•and•displays•
this•values.•
Ex)•In•case•low•limit•input•value:•-5V,•high•limit•input•
value:•+5V•and•in•case•lower•limit•scale:•-1000,•
upper•limit•scale:•1000,•if•current•input•value•is•2V,•
display•value•is•400.
In•case•voltage,•current•input•type,•this•mode•is•used•
when•input•value•is•calculated•by•Root•( )•for•the•
desired•display•value.•Differential•pressure•signal•of•
differential•pressure•ow•meter•is•calculated•Root•( )
for•the•to-be•measured•ux.•This•function•is•used•to•
measure•ux•by•input•value.
Ex)•In•case•lower•limit•input•value:•-5V,•upper•limit•input•
value:•+5V•and•in•case•lower•limit•scale:•-1000,•
upper•limit•scale:•1000,•if•current•input•value•is•2V,•
display•value•is•approx.•673.32.
①
•Ink•cartridge(model:•D33006B-66X-01)
②
•Recording•paper•cassette
Cassette•saves•the•recording•paper.
③
•Recording•paper•cassette•lever
Press•the•lever•down•and•this•recording•paper•cassette•is•
removed•from•KRN100.
※
•Remove•the•recording•paper•cassette•for•recording•paper•
replacement,•ink•cartridge•replacement.
①
•Recording•paper•holder
Movement•holder•of•recording•paper•when•recording
②
Recording•paper•storage•part
Storage•part•for•recorded•recording•paper
③
•Front•cover•of•recording•paper•storage
Open•recording•paper•guide•for•recording•paper•replacement•
④
•New•recording•paper•storage:•Storage•part•for•new•
recording•paper•(1EA•recording•paper•is•storable.)
⑤
Rear•cover•of•recording•paper•storage•
Inside
Paper cassette
③
①
②
①
②
③
⑤
④
Functions
