9.2.4 Mounting onto a Ceiling Box / Wall Box
Standard 60 mm ceiling or wall boxes can be used when mounting
the protector base onto a ceiling or wall box.
 Consult the manufacturer’s instructions delivered with the
standard ceiling or wall box
 Mount the ceiling or wall box in the ceiling as described in the
manufacturer’s instructions
 Feed the cables through the Ø25 mm cable entry as shown
 Mount the protector base onto the box by fastening the screws
