9.3.3 Wire Insulation Stripping
For proper connection, 8mm of wire insulation must be stripped.
When stripping cable insulation from wires, note that as a guidance,
a mark on the the connector indicates the wire insulation stripping
length.
 Measure the length from the edge of the connector to the strip
mark indicated on the drawing
 Use a wire stripping tool to strip the cable
