Configuration
Technical Handbook, AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339, Revision 1, 2020-06-29,
Autronica Fire and Security
Page 78
VAD Intensity
The AutroGuard® Protector’s visual alarm device (VAD) emits a white
or red light.
The following intensity settings apply:
Open category
Low
Medium
High
Note that the different settings have different current consumptions.
Always take into consideration that a high intensity will draw more
current than a low intensity, and high intensity will lead to fewer
units per detection loop.
Click the dropdown button for VAD Intensity to select one of the
following intensities:
Refer to chapter 6.5 VAD Intensity.
