X33AF Reector Plates
X33AF models are supplied with either a black or a
stainless steel reector plate. These plates are not
interchangeable. Order the replacement that matches the
reector plate on your X33AF ame detector.
PERIODIC CHECKOUT PROCEDURE
In compliance with SIL 2, a checkout of the system using the
Mag o
i
or Man o
i
feature should be performed regularly
to ensure that the system is operating properly. Refer to
Table 1 in the X33AF Safety Manual (116-P-X33AF-SIL2/
CGB) for frequency of proof tests. To test the system,
perform the “Fire Alarm Test” as described in the “Startup
Procedure” section of this manual.
CLOCK BATTERY
The real time clock has a backup battery that will operate
the clock with no external power for nominally 10 years.
It is recommended that the battery be replaced every
7 years. Return the device to the factory for battery
replacement if needed.
NOTE
If the backup battery is depleted, there is no effect
on the operation of the ame detector, but the time
stamping of the data log may be affected.
FEATURES
• Long detection range to carbonaceous res.
• Unequaled false alarm rejection.
• Responds to a re in the presence of modulated
blackbody radiation (i.e. heaters, ovens, turbines)
without false alarm.
• Microprocessor controlled heated optics for increased
resistance to moisture and ice
• Automatic, manual or magnetic optical integrity ( o
i
)
testing
• Easily replaceable o
i
plate.
• Fire, fault and auxiliary relays standard
• 0 to 20 mA isolated output (optional)
• HART communication (optional)
• EDT/DMT capable
• Multiple sensitivity levels
• A tricolor LED on the detector faceplate indicates
normal condition and noties personnel of re alarm
or fault conditions
• Operates under adverse weather conditions and in
dirty environments
• Mounting arm allows easy sighting
• Integral wiring compartment for ease of installation.
• Explosion-proof/ame-proof detector housing. Meets
FM, CSA, ATEX Directive and CE certication
requirements
• Class A wiring per NFPA-72
• Meets NFPA-33 response requirement for under 0.5
second (available when model selected)
• 5 year warranty
• RFI and EMC Directive compliant
ASSOCIATED MANUALS
List of X33AF related manuals:
TITLE FORM NUMBER
SIL 2 (Safety) 116-P-X33AF-SIL2/CGB
HART Addendum
116-P-X33AFADDENDUM/YGB,
P/N 95-8624
