Autronica AutroFlame X33AF - Appendix F - Offshore Approvals; Type Approval

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page F-1
APPENDIX F – OFFSHORE APPROVALS
MARINE EQUIPMENT DIRECTIVE
DNV Certicate No. MED-B-5872.
Is found to comply with the requirements in the following Regulations / Standards:
Annex A.1, item No. A.1/3.51 and Annex B, Module B in the Directive. SOLAS 74 as amended, Regulation II-2/7 & X/3, 2000 HSC
Code 7, FSS Code 9 and IMO MSC.1/Circ. 1242.
The equipment are found to comply with following location / application dependent requirements (for definition of each of the
location classes, see below the table):
MODEL TEMPERATURE VIBRATION EMC ENCLOSURE
X33AF TEM-D VIB-B EMC-B ENC-C
Denition of the location classes with reference to relevant standards:
Temperature
TEM-D Location (–25°C-70°C) (ref. IEC 60092-504 (2001) table 1 item 6-7)
Vibration
VIB-D For eq. on reciprocating machines etc. (ref IEC 60092-504 (2001) table 1 item 10)
EMC
EMC-B Bridge and open deck zone (ref. IEC 60092-504 (2001) table 1 item 19-20)
Enclosure
ENC-C Open deck (IP56) (ref. IEC 60092-201 table 5)
Conformity to Module D, E and F.
TYPE APPROVAL
DNV Certicate No. A-11022.
Subject Matter of the Approval
IR Flame Detector Type X3301 for use in Ships, High Speed & Light Craft, and Offshore Applications.
Application Location Classes:
TYPE APPROVAL
Lloyd's Register Certicate No. 09/00027.
Models Available: Relay output, relay 0-20 mA output, and EQP LON output versions.
The following accessories are offshore approved to the listed approvals, for use with the X33AF Flame Detector:
Part Number Description
116-102740-002 Magnet
116-007739-001 Magnet and Extension Pole
116-007290-001 Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
116-007290-002 Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
116-011385-001 Q9033 Collar Attachment
Location classes for X3301 IR Flame Detector with Mounting Arm Q9033B / Q9033A (Shaded areas show Det-Tronics approved location classes)
COLUMN 1 COLUMN 2
TYPE LOCATION WITHIN MAIN AREA
MAIN AREAS ON BOARD
Machinery
spaces
Control room,
Accommodation
Bridge
Pump room, Holds,
Rooms with no heating
Open Deck
Temperature
Inside cubicles, desks, etc. with temperature rise of 5°C or more B B B D D
All other locations A A A C D
Humidity
Locations where special precautions are taken to avoid
condensation
A A A A A
All other locations B B B B B
Vibration
On machinery such as internal combustion engines, compressors,
pumps, including piping on such machinery
B — — B B
Masts — — — — —
All other locations A A A A A
EMC (Electro-
magnetic
compatibility
All locations within specified main areas A A B A B
Enclosure
Submerged application D — — D D
Below floor plates in engine room C — — — —
All other locations B A A B C
