APPENDIX C – ATEX / CE APPROVAL
EC-TYPE EXAMINATION CERTIFICATE
DEMKO 01 ATEX 130204X
Increased Safety Model Flameproof Model
0539
FM
APPROVED
®
II 2 G
II 2 D
0539
FM
APPROVED
®
II 2 G
II 2 D
Ex d e IIC T6–T5 Gb Ex d IIC T6–T4 Gb
Ex tb IIIC T130°C Ex tb IIIC T130°C
T6 (Tamb –50°C to +60°C) T6 (Tamb –55°C to +60°C)
T5 (Tamb –50°C to +75°C) T5 (Tamb –55°C to +75°C)
IP66/IP67. T4 (Tamb –55°C to +125°C)
IP66/IP67.
Compliance with:
EN 60079-0: 2009
EN 60079-1: 2007
EN 60079-7: 2007
EN 60079-31: 2009
EN / IEC 60529: 2001.
INSTALLATION INSTRUCTIONS
The eld wiring connections in the terminal compartment are ATEX certied and accepts wiring specications from
14-24 AWG or 2.5-0.2 mm
2
.
The Multispectrum infrared (IR) ame detector type X33AF shall be installed according to the instructions given by the
manufacturer.
The cable entry devices shall be certied in type of explosion protection ameproof enclosure "d" for use with the terminal
compartment in type of explosion protection ameproof enclosure "d", or in type of explosion protection increased safety
"e" for use with the terminal compartment in type of explosion protection increased safety "e". They shall be IP66/IP67
rated, suitable for the conditions of use and correctly installed.
Unused entries shall be closed with suitable certied blanking elements.
The metal housing for the Multispectrum infrared (IR) ame detector type X33AF must be electrically connected to earth
ground.
For ambient temperatures below –10°C and above +60°C use eld wiring suitable for both minimum and maximum
ambient temperature.
Special conditions for safe use:
The front window assembly contains a special cemented joint construction. In accordance with EN60079-1 clause 5.1.c,
all inspections, repair and/or adjustments to this front window assembly shall be done by the manufacturer only.
The EOL resistor can only be used within the ameproof terminal compartment.
EOL resistors must be ceramic, wirewound type, rated 5 watts minimum, with actual power dissipation not to exceed 2.5
watts.
The Multispectrum infrared (IR) ame detector type X33AF is to be installed in places where there is a low risk of
mechanical damage.
