Autronica AutroFlame X33AF - Accessories; Replacement Parts; Device Repair and Return; Ordering Information

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page 18
ACCESSORIES
Part Number Description
116-000511-029 Converter RS485 to RS232
116-103881-001 Converter RS485 to USB
116-007819-001
W6300B1002 Serial Inspector Connector
(Inspector Monitor software included)
116-007819-002
W6300B1003 USB Inspector Connector
(Inspector Monitor software included)
116-009207-001 Flame Inspector Monitor CD
116-103922-001 Model 475 HART Communicator
116-102740-002 Magnet
116-008082-001 Magnet and Adapter for Extension Pole
116-007739-001 Magnet and Extension Pole
116-007240-001 Q1116A1001, Air Shield (AL)
116-007818-001 Q1118A1001 Aluminum Air Shield/Flange Mount (AL)
116-007818-002 Q1118S1001 Stainless Steel Air Shield/Flange Mount (SS)
116-009177-001 Q1120A1001 Paint shield mounting ring (AL)
116-010857-001 Q1130A1001 Flange Mount Assembly for X33AF & X32AF
116-006097-001 Q1201 Laser
116-102871-001 Laser Battery, 3V Lithium (laser)
116-007255-001 Q1201C1001 X-Series Laser Holder (AL/Plastic)
116-007338-001 Q2000A1001 X-Series Weather Shield (AL)
116-007338-010 Q2033A10R X33AF/X32AF FOV Limiter 10° (AL)
116-007338-020 Q2033A20R X33AF/X32AF FOV Limiter 20° (AL)
116-007338-030 Q2033A30R X33AF/X32AF FOV Limiter 30° (AL)
116-007912-010 Spare Restrictor Plate 10° (AL)
116-007912-020 Spare Restrictor Plate 20° (AL)
116-007912-030 Spare Restrictor Plate 30° (AL)
116-007290-001
Q9033B Stainless Steel Swivel Mount Assembly for
aluminum and stainless steel detectors
116-007290-002
Q9033A Aluminum Swivel Mount Assembly for aluminum
detectors only
116-011385-001 Q9033 Collar Attachment
116-101197-001 Stop Plug, 3/4 NPT, AL
116-101197-004 Stop Plug, 3/4 NPT, SS
116-101197-005 Stop Plug, M25, AL, IP66
116-101197-003 Stop Plug, M25, SS, IP66
116-010816-001 Stop Plug, 20PK, 3/4NPT, AL
116-010817-001 Stop Plug, 20PK, 3/4NPT, SS
116-010818-001 Stop Plug, 20PK, M25, AL
116-010819-001 Stop Plug, 20PK, M25, SS
116-103363-001 14 mm Hex Wrench (Steel)
116-103406-001 Screwdriver
116-107427-040 O-ring - Rear Cover (Viton)
116-005003-001 1 oz grease for detectors (non-silicon)
116-001680-001 Window cleaner (6 pack)
REPLACEMENT PARTS
The detector is not designed to be repaired in the eld.
If a problem should develop, refer to the Troubleshooting
section. If it is determined that the problem is caused by
an electronic defect, the device must be returned to the
factory for repair.
REPLACEMENT PARTS
Part Number Description
116-009208-001
o
i
Replacement kit for X33AF (5 Black Reector Plates)
with Inspector Connector and Monitor
116-010831-001
o
i
Replacement kit for X33AF (5 Stainless Steel Reector Plates)
with Inspector Connector and Monitor
116-007307-001
Replacement o
i
Reector Plates for X33AF with Black plate
(requires Inspector Connector to calibrate)
116-010830-001
Replacement o
i
Reector Plates for X33AF with Stainless Steel
plate (requires Inspector Connector to calibrate)
NOTE: Refer to instruction manual 95-8530 to determine the correct o
i
replacement plate.
DEVICE REPAIR AND RETURN
Prior to returning devices, contact the nearest local
Autronica office so that a Return Material Identication
(RMI) number can be assigned. A written statement
describing the malfunction must accompany the returned
device or component to assist and expedite nding the
root cause of the failure.
Pack the unit properly. Always use sufficient packing
material. Where applicable, use an antistatic bag as
protection from electrostatic discharge.
NOTE
Autronica reserves the right to apply a service
charge for repairing returned product damaged as
a result of improper packaging.
Return all equipment transportation prepaid to the factory
in Trondheim.
NOTE
It is highly recommended that a complete spare
be kept on hand for eld replacement to ensure
continuous protection.
ORDERING INFORMATION
When ordering, please specify:
X33AF IR Flame Detector
Refer to the X33AF Model Matrix for details
Q9033 ;Mounting Arm is required:
– Q9033A for aluminum detectors only.
– Q9033B for aluminum and stainless steel detectors.
