Autronica AutroFlame X33AF - Page 23

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page 19
X33AF MODEL MATRIX
MODEL DESCRIPTION
X33AF Multispectrum IR Flame Detector
TYPE MATERIAL
A Aluminum
S Stainless Steel (316)
TYPE THREAD TYPE
4M 4 PORT, METRIC M25
4N 4 PORT, 3/4" NPT
TYPE OUTPUTS
11 Relay
13 Relay and 4-20 mA
15 Relay and Pulse
16 Addressable Module Only (Third Party Type)
21 Relay-Automotive
23 HART, Relay and 4-20 mA
TYPE APPROVALS**
B INMETRO (Brazil)
R VNIIPO/VNIIFTRI (Russia)
T SIL/FM/CSA/ATEX/CE/IECEx
W FM/CSA/ULC*/ATEX/CE/IECEx
TYPE CLASSIFICATION
1 Division/Zone Ex d e
2 Division/Zone Ex d
*ULC approval applies to output types 11, 13, 15, 21, and 23.
**Type Approvals can use one or more letters to designate the
approvals of the product.
