Autronica AutroFlame X33AF - Appendix E - En54 Approvals

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page E-1
APPENDIX E – EN54 APPROVALS
AGENCY
Conventional Output LON Output
Certicate/Approval
Number
Basis of Approval
Certicate/Approval
Number
Basis of Approval
VdS –
Constructive Product Directive
0786 – CPD – 20453 EN 54-10 + A1 — —
VdS**
G 202136
VdS 2344
VdS 2504
EN 54-10 + A1
G 212019
VdS 2344
VdS 2504
EN 54-10 + A1
EN 54-17
S 212002*
VdS 2344
EN 54-13
S 212002*
VdS 2344
EN 54-13
BRE –
Constructive Product Directive
— — 0832 – CPD – 1381
EN 54-10 + A1
EN 54-17
LPCB 973e/03 EN 54-10 + A1 973a/03
EN 54-10 + A1
EN 54-17
* Approved for use in conjunction with the EN54-13 compliant EQP System.
** Approval of Very High, Medium, and Low sensitivities, with T-Low sensitivity pending.
INSTRUCTIONS FOR THE APPLICATION OF THE APPROVAL COMPONENT/SYSTEM
The installation shall take into account, that the orientation arrow on the ame detector is directed upwards, as the view
angle in this direction is <90°.
The IR-flame detector configured to High or Very High sensitivity corresponds to class 1.
The IR-flame detector configured to T-Low or Low sensitivity corresponds to class 2.
The following accessories are EN54 and EN54-17 approved for use with the X33AF Flame Detector:
Part Number Description
116-102740-002 Magnet
116-007739-001 Magnet and Extension Pole
116-010857-001 Q1130A1001 Flange Mount Assembly
116-007290-001 Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
116-007290-002 Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
116-011385-001 Q9033 Collar Attachment
