Autronica AutroFlame X33AF - Appendix D - Iecex Approval

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page D-1
APPENDIX D – IECEX APPROVAL
IECEx CERTIFICATE OF CONFORMITY
DEMKO
IECEx ULD 06.0017X
Ex d e IIC T6-T5 Gb Ex d IIC T6-T4 Gb
Ex tb IIIC T130°C Ex tb IIIC T130°C
T6 (Tamb =–50°C to +60°C) or T6 (Tamb =–55°C to +60°C)
T5 (Tamb =–50°C to +75°C) T5 (Tamb =–55°C to +75°C)
IP66/IP67. T4 (Tamb =–55°C to +125°C)
IP66/IP67.
Compliance with:
IEC 60079-0: 2007, ed. 5
IEC 60079-1: 2007, ed. 6
IEC 60079-7: 2006, ed. 4.
IEC 60079-31: 2008, ed. 1
EN/IEC 60529: 2001
INSTALLATION INSTRUCTIONS
The eld wiring connections in the terminal compartment are suitable certied and accepts wiring specications from
14-24 AWG or 2.5-0.2 mm
2
.
The Multispectrum infrared (IR) ame detector type X33AF shall be installed according to the instructions given by the
manufacturer.
The cable entry devices shall be certied in type of explosion protection ameproof enclosure "d" for use with the terminal
compartment in type of explosion protection ameproof enclosure "d" or in type of explosion protection increased safety
"e" for use with the terminal compartment in type of explosion protection increased safety "e".
They shall be IP66 rated, suitable for the conditions of use and correctly installed.
Unused entries shall be closed with suitable certied blanking elements.
The metal housing for the Multispectrum infrared (IR) ame detector type X33AF must be electrically connected to earth
ground.
For ambient temperatures below –10°C and above +60°C use eld wiring suitable for both minimum and maximum
ambient temperature.
Special conditions for safe use:
The front window assembly contains a special cemented joint construction. In accordance with EN60079-1 clause 5.1.c,
all inspections, repair and/or adjustments to this front window assembly shall be done by the manufacturer only.
The EOL resistor can only be used within the ameproof terminal compartment.
EOL resistors must be ceramic, wirewound type, rated 5 watts minimum, with actual power dissipation not to exceed 2.5
watts.
The Multispectrum infrared (IR) ame detector type X33AF is to be installed in places where there is a low risk of
mechanical damage.
The following accessories are IECEx approved for use with the X33AF Flame Detector:
Part Number Description
116-007290-001 Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
116-007290-002 Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
116-011385-001 Q9033 Collar Attachment
