Autronica AutroFlame X33AF - Appendix B - Csa Approval

Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page B-1
APPENDIX B – CSA APPROVAL
PRODUCTS
CLASS 4818 04 - SIGNAL APPLIANCES - Systems - For Hazardous Locations
Class I, Division 1, Groups B, C, and D (T4A); Class II, Division 1, Groups E, F, and G (T4A);
Class I, Division 2, Groups A, B, C, and D (T3C); Class II, Division 2, Groups F and G (T3C);
Class III; Enclosure NEMA/Type 4X;
Multispectrum IR Flame Detector/Controller X33AF Series, rated 18-30 Vdc, 4.6 Watts to 17 Watts.
Relay contacts rated 30 Vdc, 5 Amps.
NOTE
Hazardous location testing has been successfully completed on the Model X33AF series from an ambient
temperature range of –55°C to +125°C; however, the detector label marking indicates –40°C to +75°C.
APPLICABLE REQUIREMENT
The following accessories are CSA approved for use with the X33AF Flame Detector:
Part Number Description
116-102740-002 Magnet
116-007739-001 Magnet and Extension Pole
116-010857-001 Q1130A1001 Flange Mount Assembly
116-007290-001 Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
116-007290-002 Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
116-011385-001 Q9033 Collar Attachment
CSA Std C22.2 No. 25-1999 – Enclosures for use in Class II Groups E, F & G Hazardous Locations.
CSA Std C22.2 No. 30-M1986 – Explosion-Proof Enclosures for use in Class I Hazardous Locations.
CAN/CSA C22.2 No. 94-M91 – Special Purpose Enclosures.
CSA Std C22.2 No. 142-M1987 – Process Control Equipment.
CSA Std C22.2 No. 213-M1987 – Nonincendive Electrical Equipment for use in Class I, Division 2 Hazardous Locations.
