Instructions, AutroFlame X33AF, 116-P-X33AF/IGB, rev. E, 2013-08-13, P/N 95-8625-17.1, Rev: 2/13
Autronica Fire and Security AS
Page A-7
FM Approval and Performance Report – Continued
Medium Sensitivity
Fuel Size
Distance
feet (m)
Horizontal
(degrees)
Avg. Horiz.
Response Time
(seconds)
Vertical
(degrees)
Avg. Vert.
Response Time
(seconds)
n-Heptane 1 x 1 foot
75
(22.9)
+45
-45
9
6
+45
-30
10
7
n-Heptane 1 x 1 foot
50
(15.2)
+45
-45
4
3
+45
-30
3
3
Diesel** 1 x 1 foot
60
(18.3)
+45
-45
4
4
+45
-30
4
2
Ethanol 1 x 1 foot
60
(18.2)
+45
-45
12
9
+45
-30
12
9
Methanol 1 x 1 foot
50
(15.2)
+45
-45
9
3
+45
-30
9
1
Methane 32 inch plume
45
(13.7)
+45
-45
3
3
+45
-30
7
1
JP-5** 2 x 2 feet
90
(27.4)
+45
-45
4
2
+45
-30
2
2
Office Paper 0.5 lb. 19" x 19" x 8"
40
(12.2)
+45
-45
2
1
+45
-30
1
1
Corrugated Panel 18" x 36"
40
(12.2)
+45
-45
2
1
+45
-30
1
1
** Pre-burn from ignition.
T-Low Sensitivity
Fuel Size
Distance
feet (m)
Horizontal
(degrees)
Avg. Horiz. Response
Time (seconds)
Vertical
(degrees)
Avg. Vert. Response
Time (seconds)
n-Heptane 1 x 1 foot
35
(10.7)
+45
-45
7
7
+45
-30
7
7
Methanol 1 x 1 foot
15
(4.6)
+45
-45
5
5
+45
-30
5
5
Methane
32 inch
plume
15
(4.6)
+45
-45
4
4
+45
-30
4
4
Low Sensitivity
Fuel Size
Distance
feet (m)
Horizontal
(degrees)
Avg. Horiz. Response
Time (seconds)
Vertical
(degrees)
Avg. Vert. Response
Time (seconds)
n-Heptane 1 x 1 foot
35
(10.7)
+45
-45
13
13
+45
-30
9
18
Methanol 1 x 1 foot
15
(4.6)
+45
-45
14
12
+45
-30
10
8
Methane
32 inch
plume
15
(4.6)
+45
-45
10
11
+45
-30
8
10
