Appendix
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FO/FE Rev. E, 021105,
Autronica Fire and Security AS
Page 123
15.2.5 Configuration Example
An example of a typical configuration would be as follows:
• Each single room with one or several detectors is defined as a
Detection Zone, DZ1, DZ2, etc.
• Each corridor and stairway is defined as a Detection Zone.
• Two main sections on each floor, divided by a fire wall, are each
defined as an Alarm Zone, AZ1 and AZ2. These alarm zones are
also defined as neighbour alarm zones.
• The entire building, controlled and monitored by a Fire Alarm
Control Panel (operator panel), is defined as an Operation Zone,
OZ.
