Actions to be Taken in the Event of Faults
Ste
p
Actions to be
taken
Display Indication Audible Indication
1
Notify service/technical
personnel.
The internal buzzer on
the operator panel is
turned on.
Comments: The yellow FAULT indicator starts to blink.
2
To silence the internal
buzzer, press the black
Mute Panel button
The internal buzzer on
the operator panel is
turned off.
3
Press and observe
the fault warnings in the
display.
Comments: In this example, points in detection zone (1 OFFICES) are in fault warning
state. Both the detection zone and the related loop, are registered as fault
warnings (Total 2).
NOTE: An audible indication of loss of POWER can not be silenced. The
internal buzzer is automatically resounded for each newly recognized fault.
4
Make service/technical
personnel investigate
the scene(s) and carry
out the necessary
actions.
5
To select a fault warning
(if there are several fault
warnings), scroll with
the arrow buttons
6
PQR
or
9
YZ
6
To view detailed
information for the
selected fault warning
(in this example,
«OFFICES»), press
Comments:
Note that other types of faults are operated differently than what is described
in this example. A Fire Alarm Device (FAD) in fault warning state, for example,
can be accepted at this stage by pressing Action Digit 3 (ACCEPT FAULT
WARNING).
If you want to view detailed information on other fault warnings, you have to
press the CLOSE button, then repeat step 5 and 6. If you want to accept
each fault warning in turn, go directly to step 7.
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP (2)
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP (2)
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP (2)
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP (2)
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP
2
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP
2
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP (2)
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP (2)
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP
2
FAULT WARNINGS
19:23
Total: 2
Total: 1
Total: 1
DZ FAULTS
1 OFFICES
OTHER FAULTS
1 LOOP
2
FAULT INFO
UNIT IN FAULT: OFFICE
TYPE:
DATA
OPERABILITY
DATA: 0
(REPORTED BY (F/L/S): 30001/687/0
19:23
1: SHOW POINTS
FAULT INFO
UNIT IN FAULT: OFFICE
TYPE:
DATA
OPERABILITY
DATA: 0
(REPORTED BY (F/L/S): 30001/687/0
19:23
1: SHOW POINTS
