If the engine temperature exceeds 115 Deg the rev limiter will dramatically reduce the
engines maximum RPM making it impossible to damage the engine due to overheating.
Cut fuel/ign pattern
Fuel/Ignition cut pattern.
ECU cuts fuel/ignition by using 10 sequence cut pattern.
Pattern bits are for each cylinder 87654321.
0=Off, 1=On Default pattern for cylinders is
Cylinders
=========
87654321
=========
11111111 ;Pattern 1 This value only !!
11111111 ;Pattern 2 This value only !!
11101110 ;Pattern 3
11101110 ;Pattern 4
10101010 ;Pattern 5
10101010 ;Pattern 6
10001000 ;Pattern 7
10001000 ;Pattern 8
00000000 ;Pattern 9 This value only !!
00000000 ;Pattern 10 This value only !!
Anti-lag setup
You need to enable this function by assigning it an O/P before you can use it.
You assign O/Ps under "M1","O/P setup"
