Accuracy, Color protection, Initial map state & sensor position (Base fuel only).
Table properties
Shows the table properties.
Sites Used.
How many sites used by table
Maximum sites
How many are possible
Also shows if any axis is common to other tables.
Tag item
You can tag cells so that only those cells are edited via tagging functions.
You may want to multiply only selected cells or load selected cells from another
calibration.
Edit-Window - Tagged Mode
Linear left to right
Linear interpolates from left to right.
• When in tagged mode, only modifies data from tagged cells.
• When in tagged mode uses the last tagged cell as basis for interpolating.
Linear top to bottom
Linear interpolates from top to bottom.
• When in tagged mode, only modifies data from tagged cells.
• When in tagged mode uses the last tagged cell as basis for interpolating.
EXP left to right
Exponential function left to right.
You can select the gradient for this.
• When in tagged mode, only modifies data from tagged cells.
• When in tagged mode uses the last tagged cell as basis for exponential function.
EXP top to bottom
Exponential function top to bottom
You can select the gradient for this.
• When in tagged mode, only modifies data from tagged cells.
• When in tagged mode uses the last tagged cell as basis for exponential function.
Edit-Window - Strip chart
Select X axis
“X” key
Selects the X axis for displaying the strip chart.
When select SEC as X axis, its a standard time strip chart but when select Engine speed
then its a XY strip chart.
