Divider offset:
Adjust until "Sync/Cyl" is between 20%..80%
Typical
Subaru WRX 01..05=16
NOTE
Cannot be larger then "EFP divider factor"-1.
Number of missing teeth:
Typical
0=Pre-scalar only.
1=36-1 Ford type.
2=60-2 Motronic type and 36-2 Toyota type.
Sync on missing pulse:
Enabled for single sensor triggering.
Typical=Disabled
Enabled
4 stroke with missing teeth on the camshaft once per engine cycle.
2 stroke with missing teeth once per engine cycle.
Cylinder Sensor
Cylinder sensor type
1. Reluctor
Sensor polarity must be as follows. On plus input pin, wave should rise first
then fall through trigger point.
2
.
2. Hall
Connect sensor to +ve input pin only. No connection to -ve input pin allowed.
Either shorten -ve input lead back to shield or cut wire near connector pin.
All two wire sensors are magnetic. Some three wire sensors are also magnetic.
Three wire sensors with power supply are Hall Effect.
Cylinder trig edge
Cylinder trigger edge.
Which edge to trigger on.
1. Rising
2. Falling
