The Boost SW1 that is inverted means function is normally on and off when channel 7 is
grounded. A function that is inverted will be on (even if the wire is not connected at all)
and when grounded off.
Some channels have selectable thresholds; if set to 50% the channel switch at 2.5 Volt
(I/P analogs are 0 - 5 volt, 0% =ground and 100% = 5 volt).
If set to 20% it will switch at 1.0 Volt. If you want a I/P function that is off at 0 to 1.0 volt
and on at 1.1 to 5.0 you select threshold 20% and Inverts the I/P (if not inverted it will be
on 0 to 1.0 volt and off at 1.1 to 5.0).
The I/P GP functions can be used to store variables and using it in other functions like
GPC.
