AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
117
NO.
Material code
Part name
Qty
1
11220502004504
Panel
1
2
11222014000521
Display board assembly
1
3
11220508000142
Filter
2
4
11320096000105
Screw cover
3
5
11220509000062
Medium frame wiring cover
1
6
11320078000196
Right-side cover
1
7
11320065000028
Breakwater
1
8
11220513000067
Air blade
2
9
11230003000127
Indoor motor
1
10
11320052000032
Motor cover
1
11
11221526000003
Cover of electric controller box
1
12
11320079000013
Step motor shaft sleeve
1
13
11230002000058
Step motor
1
14
11321012000005
Controller box sheet-metal A
1
15
11222003002779
Main PCB
1
16
11320084000015
Pipe clamp
1
17
11321003000028
Mounting plate assembly
1
18
11320001000216
Chassis
1
19
11320005000386
Volute
1
20
11220551000003
Cross flow fan rubber bearing
1
21
11320080000007
Pubber bearing fixing peg
1
22
11220513000067
Cross flow fan assembly
1
23
11224003000659
Evaporator assembly（07/09）
1
11224003000547
Evaporator assembly（12）
24
11320002000310
Medium frame
1
25
11320078000197
Left-side cover
1
26
11320135000015
Air louver
1
27
11320061000275
Decoration board
1

AUX AMWM-H09/4R3 Specifications

General

Brand	AUX
Model	AMWM-H09/4R3
Category	Air Conditioner
Language	English
