AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
Part4 Specification
1. Wall Mounted
1.1 L Series (07K,09K)
Model
Indoor
Unit
AMWM-H07/4R3(L*)
AMWM-H09/4R3(L*)
Capacity
Cooling
Btu/h
7165(3855-9220)
8701(3412~11260)
kW
2.05(1.13-2.70)
2.55(1.00~3.30)
Heating
Btu/h
7510(3340-8530)
9042(3753~11260)
kW
2.15(0.98-2.50)
2.65(1.10~3.30)
Electric Data
Power Supply
V~,Hz,Ph
220～240,50,1
220～240,50,1
Cooling Power
W
40(12～68)
40(12~68)
Heating Power
W
40(12～68)
40(12~68)
Indoor
Fan Motor
Model
/
YYK18-4B
YYK18-4B
Output Power
W
18
18
Speed (H/M/L)
r/min
1250
1250
Indoor Coil
Number Of Row
/
2
2
Tube x Row
Pitch
mm
20.5x 12.7
20.5x 12.7
Fin Pitch
mm
1.4
1.4
Fin Material
/
Hydrophilic aluminum fin
Tube Material
mm
φ7， Inner grooved
Performance
Air Flow Volume
m
3
/h
650
650
Sound Pressure
dB(A)
51
54
Dimension
Net Dim
(W*D*H)
mm
800*300*198
800*300*198
Pack Dim
(W*D*H)
mm
870*370*282
870*370*282
Weight
Net
kg
9
9
Gross
kg
10.5
10.5
Refrigerant Type
/
R32
R32
Pipe Dia.
Liquid Side
mm(inch)
6.35(1/4)
6.35(1/4)
Gas Side
mm(inch)
9.52(3/8)
9.52(3/8)
Drainage
mm
16.5
16.5
Loading Qty
20/40/40H
unit
320/680/765
320/680/765
