AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
119
NO
Material code
Part Name
Qty
1
11320003003301
Panel
1
2
11320005000388
air louver（Horizontal）
1
3
11320094000054
Decoration board
1
4
11222014000522
Display board assembly
1
5
11220508000144
Filter
2
6
11320076000057
Medium frame wiring cover
1
7
11321071000006
Medium frame wiring cover scale board
1
8
11320096000104
Screw cover
2
9
11320078000207
Left-side cover
1
10
11320002000311
Medium frame
1
11
11320078000206
Right-side cover
1
12
11320065000028
Breakwater
1
13
11222001000112
Remote control
1
14
11224003000602
Evaporator assembly
1
15
11320017000107
Air blade
3
16
11320135000007
Volute
1
17
11220513000058
Cross flow fan assembly
1
18
11230002000071
Step motor
1
19
11320001000191
Chassis
1
20
11221500000028
Mounting plate assembly
1
21
11320084000015
Pipe clamp
1
22
11230002000071
Step motor
1
23
11320079000016
Step motor shaft sleeve
1
24
11222003002753
Main control assembly
1
25
11230005000013
Indoor motor
1
26
11320052000034
Motor cover
1
