AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
No.
Chinese Name
Part Name
BOM Code
Qty
1
格栅
air return grille
16420012000002
2
2
滤网
Filter net
16420010000002
2
3
左装饰板
Adornment board
16420015000002
1
4
电器盒
electric control box
16421038000364
1
5
电控盒盖
Electric cover plate
16421005000205
1
6
端子板
Terminal plate
16427001000087
1
7
端子板
Terminal plate
16427001000064
1
8
控制板
PCB
11222541000051
9
左盖板
Left cover plate
16420014000007
1
10
左挂架
Left pylons
16421001000029
1
11
左侧板组件
Left side plate assembly
16321006000005
1
12
背板组件
chassis assembly
16421018000004
1
13
蒸发器总成
Evaporator assembly
16324018000015
1
14
导风门
Guide the wind vane
16420005000005
1
15
顶盖板
Top cover plate
16420014000016
1
16
顶泡沫
Top Foam
16428001000088
1
17
导风架
Holder support
16420006000007
1
18
步进电机
Motor Assembly
16430001000604
1
19
步进电机
Motor Assembly
16430031000001
1
20
垂直叶片连杆 A
Vertical vame connecting rod
16420008000003
1
21
垂直叶片
Vertical blade
16420007000008
9
22
右侧板组件
Right side plate assembly
16321006000006
1
23
右挂架
Right pylons
16421001000030
1
24
右盖板
Right cover plate
16420014000008
1
25
集水盘组件
Drain pan
16421002000503
1
26
塑料排水软管
Drain pipe
16432019000021
1
27
电机固定板
Motor fixing plate
16421002000190
1
28
直流电机架
Motor support
16421035000057
1
29
直流电机
Motor
16430001000504
1
30
风轮
Wind wheel
16444001000013
2
31
上蜗壳
Upper spiral case
16444002000014
2
下蜗壳
Lower spiral case
16444002000015
2
32
R 显示灯板
Display lamp board
11222023000333
1
33
显示盒
Display box
16420017000002
1
34
面板
panel
16420013000019
1
