AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
No.
Chinese Name
Part name
Part code
Qty/Per
1
前面板
Front panel
11321005000107
1
2
出风网罩
Plastic grille
11320026000061
1
3
风叶
Fan blade
11320009000063
1
4
左侧板
Left side panel
16421001000729
1
5
冷凝器
Condenser asm
16324002000103
1
6
电机支架
Motor bracket
11321002000040
1
7
电控总成
Electric board asm
11222550000016
1
8
顶盖板
Top cover
11321009000057
1
9
四通阀
4-way valve asm（14）
16325002000669
1
4-way valve asm（18）
16325002000665
1
10
右侧板
Right side panel
16421001000757
1
11
端子盖
Electrical cover
11320068000009
1
12
阀盖板
Check valve cover
16420014000039
1
13
电子膨胀阀
E-expensivevalve body
16441014000030
2
14
背侧板
Back side panel
16421001000758
1
15
压缩机
Compressor（14）
16438004000119
1
Compressor（18）
11223003000331
1
16
电抗器
Resistor
11330034000020
1
17
截止阀盖板
Mid-bulkhead
16420014000039
1
18
电机
Fan motor
11230005000012
1
5.2 21K， 27K

AUX AMWM-H09/4R3 Specifications

General

Brand	AUX
Model	AMWM-H09/4R3
Category	Air Conditioner
Language	English
