AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
No.
Chinese Name
Part name
Part code
Qty/Per
1
控制器总成
Electric board asm
11222550000021
1
1.1
电控盒
Electric Box
11320057000110
1
1.2
电控盒盖
Electric Box cover
11320058000088
1
1.3
控制板
PCB
11222542000106
1
1.4
散热器
Radiator
11329031000064
1
2
电器盖板
Electrical cover
11320068000006
1
3
阀板
valve cover
16421014000090
1
4
截止阀
Stop Valve
16441004000088
1
5
截止阀护套
Valve protector
11320101000044
1
6
右侧板
Right side panel
11321157000040
1
7
压缩机及其附件
Compressor
16438004000118
1
8
气液分离器
Liquid Gas Separator
16442023000051
1
9
底盘组件
Chassis
16321018000008
1
10
小面板
Small Front panel
11321005000100
1
11
面板网罩
Plastic grille
11320026000057
1
12
大面板
Big Front panel
11321005000099
1
13
左侧板
Left side panel
11321156000010
1
14
顶盖板
Top cover
11321009000054
1
15
隔风立板
Separate panel
11321025000074
1
16
顶盖板海绵
Sponge
11327014000063
1
17
轴流风叶
Fan blade
11320009000061
1
18
直流电机
Fan motor
16430033000043
1
19
电机架
Motor bracket
11321002000038
1
20
电抗器
Reactor
11330034000012
2
21
回气管组件
Gas pipe asm
16325018000028
1
21.1
低压开关
Low pressure switch
16442024000005
1
22
四通阀组件
Four way valve
16325020000032
1
23
排气管组件
Exhaust pipe
16325017000028
1
23.1
消音器
Silencer
11325512000011
1
23.2
高压开关
High pressure switch
16442024000006
1
23.3
油分离器
Oil separator
16442021000020
1
25
截止阀接管组件
Stop valve
16325033000002
1
26.1
电子膨胀阀
E-expensive valve body
16441014000030
5
27
冷凝器总成
Condenser asm
16324020000053
1
