AUX DC Inverter Free Match 50HZ R32
37
2.8 J Series (24K)
Model
Indoor
Unit
AMWM-H24/4R3(J*)
Capacity
Cooling
Btu/h
23986(9895~24908)
kW
7.03(2.90~7.30)
Heating
Btu/h
24054(7165~27296)
kW
7.05(2.10~8.00)
Electric Data
Power Supply
V~,Hz,Ph
220～240,50,1
Cooling Power Input
W
63(16~88)
Heating Power Input
W
63(16~88)
Indoor Fan Motor
Model
/
YYK50-4
Output Power
W
50
Speed (H/M/L)
r/min
1230.0
Indoor Coil
a.Number Of Row
/
2
b.Tube Pitch(a)x Row Pitch(b)
mm
20.5x 12.7
c.Fin Pitch
mm
1.4
d.Fin Material
/
Hydrophilic aluminum fin
e.Tube Outside Dia.And
Material
mm
φ7， Inner grooved
f.Coil Length x Height x Width
mm
850*41*18
Performance
Air Flow Volume
m3/h
1150
Sound Pressure Noise Level
dB(A)
49/43/37
Sound Pressure Noise Level
dB(A)
59
Dimension
Net Dimension (W*D*H)
mm
1132*330*232
Packing Dimension (W*D*H)
mm
1205*400*317
Weight
Net
kg
14
Gross
kg
17
Refrigerant Type
/
R32
R32
Pipe Diameter
Liquid Side
6.35(1/4)
6.35(1/4)
Gas Side
9.52(3/8)
15.88(5/8)
Drainage
16.5
16.5
Stuffing Quantity
20/40/40H
154/336/384
Note:
1. Cooling capacity test Condition:(27℃DB,19℃WB Indoor/35℃DB,24℃WB Outdoor);
Heating capacity test Condition:(20℃DB Indoor/7℃DB,6℃WB Outdoor);
Connecting pipe length: 7.5M.
2. Data may be changed with unit improvement. We keep the right to change the data or
specifications without prior notice, please follow the data listed on the nameplate.
