AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
4.2 12，18K
Model
Indoor
AMSD-H12/4R3A
AMSD-H18/4R3A
Capacity
Cooling
Btu/h
12280(5835-13135)
17400(8530-19790)
kW
3.60(1.71-3.85)
5.10(2.50-5.80)
Heating
Btu/h
13650(6480-13375)
19790(9690-21835)
kW
4.00(1.90-3.92)
5.80(2.84-6.40)
Electric Data
Power Supply
V~,Hz,Ph
220~240,50,1
220~240,50,1
Cooling Power
Input
W
55
75
Heating Power
Input
W
55
75
Fan Motor
Model
FP40B-ZL
FP90C-ZL
Output Power
W
40
90
Capacitor
uF
/
/
Speed (Hi/Mi/Lo)
r/min
1050/900/800
1020/870/800
Indoor Coil
Number Of Row
2
2
Tube x Row Pitch
mm
20.5x 12.7
20.5x 12.7
Fin Pitch
mm
1.4
1.4
Fin Material
Hydrophilic aluminum
Hydrophilic aluminum
Tube Dia.&
Material
mm
φ7， Inner grooved
φ7， Inner grooved
Coil L x H x W
mm
541x255x 25.4
840x255x 25.4
Heat Exchange
Area
m
2
5.01
7.78
Performance
Air Flow Volume
CFM
400/329/265
506/388/353
m
3
/h
680/560/450
860/660/600
Sound Pressure
Noise Level
dB(A)
38/34/31
42/38/36
Sound Power
Noise Level
dB(A)
53
55
ESP
Pa
10
10
Dimension
Net Dim (W*D*H)
mm
700×470×200
1000×470×200
Packing
Dim(W*D*H)
mm
1005×580×275
1305×580×275
Weight
Net
kg
18.5
24
Gross
kg
22
28
Refrigerant Type
R32
R32
Pipe Dia
Liquid Side
mm(inch)
6.35(1/4)
6.35(1/4)
Gas Side
mm(inch)
12.7(1/2)
12.7(1/2)
Drainage
mm
16.5
16.5
Loading Qty
20/40/40H
unit
176/368/414
136/288/324
