AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
Outdoor Fan
Material
Plastic
Plastic
Diameter
mm
Ф421×117
Ф421×117
Fan Quantity
1
1
Outdoor Coil
a. Number Of Row
2
2
b. Tube Pitch(a)x
Row Pitch(b)
mm
22x19.05
22x19.05
c. Fin Pitch
mm
1.3
1.3
d. Fin Material
Hydrophilic aluminum fin
e. Tube Outside
Dia. And Material
mm
φ7， Inner grooved
f. Coil Length x
Height x Width
mm
757×506×38.1
757×506×38.1
Air Flow Volume
CFM
1353
1353
m
3
/h
2300
2300
Noise Level
Sound Pressure
Noise Level
dB(A)
54
55
Sound Power Noise
Level
dB(A)
61
62
Dimension
Net Dimension
(W*D*H)
mm
800×315×545
800×315×545
Packing Dimension
(W*D*H)
mm
920×400×620
920×400×620
Weight
Net
kg
34
36
Gross
kg
37
39
Refrigerant
type/Quantity
Type
R32
R32
Charged Volume
kg
0.92
0.95
Piping
Liquid Side
mm(inch)
2×6.35(1/4)
2×6.35(1/4)
Gas Side
mm(inch)
2×9.52(3/8)
2×9.52(3/8)
Max. length for all
rooms (m)
m
40
40
Max. length for one IU
(m)
m
25
25
Max. height
difference between IU
and OU (m)
m
15
15
Max. height
difference between
IUs (m)
m
10
10
Ambient Temp (Cooling/Heating)
℃
-15~52℃/-15~24℃
-15~52℃/-15~24℃
Stuffing
Quantity
20/40/40H
unit
102/219/292
102/219/292
