AUX AMWM-H09/4R3 - Page 48

AUX DC Inverter Free Match 50HZ R32
Diameter
mm
Ф470×140
Ф470×140
Fan Quantity
1
1
Outdoor Coil
a.Number Of Row
2
2
b.Tube Pitch(a)x
Row Pitch(b)
mm
22x19.05
22x19.05
c.Fin Pitch
mm
1.5
1.5
d.Fin Material
Hydrophilic aluminum
fin
Hydrophilic
aluminum fin
e.Tube Outside
Dia.And Material
mm
φ7， Inner grooved
φ7， Inner grooved
f.Coil Length x
Height x Width
mm
757×616×38.1
757×616×38.1
Air Flow Volume
CFM
1824
1824
m
3
/h
3100
3100
Noise Level
Sound Pressure
Noise Level
dB(A)
56
58
Sound Power
Noise Level
dB(A)
65
65
Dimension
Net Dimension
(W*D*H)
mm
834×328×655
834×328×655
Packing
Dimension
(W*D*H)
mm
945×435×725
945×435×725
Weight
Net
kg
44
46
Gross
kg
47
49
Refrigerant
type/Quantity
Type
R32
R32
Charged Volume
kg
1.1
1.05
Piping
Liquid Side
mm(inc
h)
3×6.35(1/4)
3×6.35(1/4)
Gas Side
mm(inc
h)
3×9.52(3/8)
3×9.52(3/8)
Max. length for all
rooms (m)
m
60
60
Max. length for
one IU (m)
m
30
30
Max. height
difference
between IU and
OU (m)
m
15
15
Max. height
difference
between IUs (m)
m
10
10
Ambient Temp (Cooling/Heating)
℃
-15~52℃/-15~24℃
-15~52℃/-15~24℃
Stuffing
Quantity
20/40/40H
unit
96/198/198
96/198/198
