AUX AMWM-H09/4R3 User Manual

AUX DC Inverter Free Match 50HZ R32
Speed
r/min
940
940
Outdoor Fan
Material
Plastic
Plastic
Diameter
mm
Ф550×125
Ф550×125
Fan Quantity
1
1
a.Number Of
Row
3
3
b.Tube Pitch(a)x
Row Pitch(b)
mm
20.5x19.05
20.5x19.05
c.Fin Pitch
mm
1.5
1.5
d.Fin Material
Hydrophilic
aluminum fin
Hydrophilic aluminum
fin
e.Tube Outside
Dia.And Material
mm
φ7， Inner grooved
φ7， Inner grooved
f.Coil Length x
Height x Width
mm
1070x759x38.1
1070x759x38.1
g.Heat
Exchanging Area
m
2
58.33
58.33
Air Flow Volume
CFM
2353
2471
m
3
/h
4000
4200
Noise Level
Sound Pressure
Noise Level
dB(A)
61
61
Sound Power
Noise Level
dB(A)
68
68
Dimension
Net Dimension
(W*D*H)
mm
985×395×808
985×395×808
Packing
Dimension
(W*D*H)
mm
1105×495×895
1105×495×895
Weight
Net
kg
74
75
Gross
kg
78
79
Refrigerant
type/Quantity
Type
R32
R32
Charged Volume
kg
2.3
2.3
Additional charge
(g/m)
20
20
Piping
Liquid Side
mm(inch)
4×6.35(1/4)
5×6.35(1/4)
Gas Side
mm(inch)
4×9.52(3/8)
5×9.52(3/8)
Max. length for
all rooms (m)
m
80
80
Max. length for
one IU (m)
m
35
35
Max. height
difference
between IU and
OU (m)
m
15
15
Max. height
difference
between IUs (m)
m
10
10
Ambient Temp (Cooling/Heating)
℃
-15~52/-15~24℃
-15~52℃/-15~24℃

AUX AMWM-H09/4R3 Specifications

General

Brand	AUX
Model	AMWM-H09/4R3
Category	Air Conditioner
Language	English
