Avant 755i 760i Storage, Transport, Tie down points and Lifting
97
Storage, Transport, Tie down points and
Lifting
Before transporting or lifting:

Mount the articulation frame lock, see page 105

Lower the boom down
Always lock the frame lock before transporting or
lifting the loader. Also remember to remove the
frame lock and test the steering of the loader after
transport.
.
Tie down points
The loader must be tied down securely if transporting
it on a trailer, for example. All four tie down points
must be used. If an attachment is fitted, also it must
be tied down.
As standard, there are 4 tie down points:

Two on the front frame, close to the boom

Two on the rear frame, near rear counterweight
Tie down points at the front of the loader:
Tie down points at the rear of the loader:
