Avant 755i 760i Storage, Transport, Tie down points and Lifting
99
.
Tie down options
Optional equipment for frequent trailer transport
If transporting the loader frequently on a trailer,
optional tie down brackets are available for easier
securing of load.
Tie down bracket A418623 installed at the rear
bumper or counterweight
Tie down bracket A418623 installed at the side of
rear frame
For side installation, two brackets are needed.
Tie down bracket on wheel hub A423091
Installed to a wheel hub with 5 bolts:
.
DANGER
Risk of moving or falling
loader - Never lift
or tie down
loader from side
counterweights.
Eyelets on extra
side counterweights are for
installing or removing the side
counterweight only. Never attempt
to lift the loader from the
counterweights or use them as tie-
down points.
eyelet
s from the counterweights
immediately after installation
work.
