BCM50 System Start Up
NN40010-318 Issue 1.2 BCM50 Rls 6.0 25
3. Click on the LAN Interfaces tab. Select the Customer LAN row, and
click Modify in the lower part of the screen.
4. Enter the IP Settings as required. You can choose to:
Obtain an IP Address, Subnet Mask, and Default Gateway
automatically (refer to the DHCP Guide for more information
on BCM and DHCP).
Enter an IP Address, Subnet Mask and Default Gateway
manually.
Note: If there is an existing DHCP server on the network, it is recommended
that you specify a static IP Address for the BCM. See the network
administrator about obtaining a static IP Address. Obtaining an IP Address
automatically should generally only be selected when the BCM is acting as
the DHCP Server for the network. Alternatively, consult the network
administrator about reserving an IP Address for the BCM on their DHCP
server.
