Page 58 DECT - Installation Manual
The Repeater Setup Program 38HBKD0001SAH – Issue 14 (27th October 2003)
The Repeater Setup Program
Before a Repeater can be used, it must be setup with various settings; e.g.
the base station number, system number, etc. The Repeater Setup
program runs on a Windows based PC and require the serial lead and
phone doubler from a DECT Repeater Programming kit.
Installing the Repeater Setup Program
The Repeater Setup program is supplied on floppy disks as a self-
installing program. It is also available from the web site
(https://emea-businesspartner.avaya.com/index.asp
) as a self-extracting
file.
Windows 3.x
1. Insert the first disk.
2. In program Manager, select File and then Run.
3. Type a:\setup.exe and then click on OK.
4. Follow the on-screen instructions for installing the CCFP Admin
program.
Windows 95/NT
1. Insert the first floppy disk.
2. Click on Start. Select Settings and then Control Panel.
3. Select Add/Remove Programs.
4. In the Add/Remove Programs Properties menu click on the
Install/Uninstall tab. Click on the Install button.
5. Windows will scan the floppy disk for a suitable installation file.
6. When it has located the file setup.exe on the floppy disk, click on
Finish.
7. Follow the on-screen instructions for installing the CCFP Admin
program.
Connecting a Repeater for Programming
The Repeater Setup kit includes a phone socket doubler and a Serial lead.
The serial lead incorporates special components, do not use any
other serial lead.
1. Use the doubler to connect the serial lead to the Repeater in parallel
with the power supply connector. Ensure that the power supply is on.
2. Connect the serial lead to the PC on which the Repeater Setup
program is installed.
