Switch Administration
2-10 Issue 6 September 2001
18. Submit the form.
19. If the hardware is present, install the RCs. (See Chapter 3, “Hardware
Installation,” for specific information before returning to this step.) If the
hardware is not present, execute the change circuit-packs command for
the port network in which the RC circuit pack will reside.
Figure 2-7. Circuit Packs Form
20. Enter TN789 into the appropriate fields and submit the form.
NOTE:
Designating the TN789 RC circuit pack in lieu of actually installing it is
known as “logically” administering the circuit pack. This enables the
installation to continue without the hardware because the system
verifies that these fields are populated. When the circuit pack arrives,
it can simply be inserted into its previously designated slot.
21. Execute the list configuration all command to generate the System
Configuration form, as follows:
CIRCUIT PACKS
Page 2 of 5change ciruit-packs
Cabinet: 1 Carrier: B
Carrier Type: port
Slot Code Sfx Name
00:
01: TN570 EXPANSION INTF
02: TN763 C AUXILIARY TRUNK
03: TN726 DATA LINE
04: TN771 D MAINTENANCE/TEST
05: TN753 DID TRUNK
06: TN767 DS1 INTERFACE
07: TN760 B TIE TRUNK
08: TN464 F DS1 INTERFACE
09:
10: TN789 RADIO CONTROLLER
‘#’ indicates circuit pack conflict.
Slot Code Sfx Name
11: TN753 DID TRUNK
12: TN789 RADIO CONTROLLER
13: TN577 PGATE BOARD
14: TN789 RADIO CONTROLLER
15: TN789 RADIO CONTROLLER
16:
17: TN767 DS1 INTERFACE
18: TN742 ANALOG LINE
19:
20:
Cabinet Layout: five-carrier
To Next Page
