Hardware Installation
3-10 Issue 6 September 2001
Table 3-2. TN789 RC Circuit Pack Pin Configuration
Color PIN Lead Name Function
W-BL 26
BL-W 1
W-O 27 URTIPA WFB-A
O-W 2 URRNGA WFB-A
W-G 28 UTTIPA WFB-A
G-W 3 UTRNGA WFB-A
W-BR 29
BR-W 4
W-S 30 URTIPB WFB-B
S-W 5 URRNGB WFB-B
R-BL 31 UTTIPB WFB-B
BL-R 6 UTRNGB WFB-B
R-O 32
O-R 7
R-G 33
G-R 8
R-BR 34
BR-R 9
R-S 35
S-R 10
BK-BL 36
BL-BK 11
BK-O 37
O-BK 12
BK-G 38
G-BK 13
BK-BR 39 STXT.0 Future Use SYNC 0 OUTPUT
BR-BK 14 STXR.0 Future Use SYNC 0 OUTPUT
BK-S 40 SPXT.0 Future Use SYNC 0 INPUT
S-BK 15 SPXR.0 Future Use SYNC 0 INPUT
Y-BL 41
